| Parameter | ELT-0321 Specification Details |
|---|---|
| Heating Media | Heating Oil, Sealed Oil Filled |
| Power (KW) | 4KW, Single Phase 110V/220V |
| Drum Diameter | Hard Chrome Drum 210mm (8.27”) |
| Transfer Speed | 1.1m/min (43.3”/min) |
| Temperature | Up to 240℃ (464℉) |
| Heat Element | 6 pcs |
| Drum Width | 300mm (11.81”) |
| Spacers | 10 pcs |
| Application | Roll-to-roll (ribbon, lanyard, belt, garment, etc.) Feeding through the bottom of the drum |
| Rollers | 2 feeding rollers & 2 inflatable collecting rollers |
| Air Cylinder | Yes |
| Machine Size | 1.40 * 1.30 * 0.58m (55.12” x 51.18” x 22.83”) |
| Packing Size | 1.54 * 0.94 * 1.45m (60.63” x 37.01” x 57.09”) |
| N.W. / G.W. | 348kgs (767.20lb) / 418kgs (921.73lb) |
How long is the experience of the manufacturing team in this industry?
Our technical and support team has been working actively in the sublimation and printing industry since 2002.
What is the standard warranty on the machines?
The standard product warranty is 1 year. The warranty can be optionally extended with an additional 5% cost per year.
What technical support services do you offer?
We provide free technical consultations and comprehensive online support. Overseas onsite technical installation and support can also be arranged with necessary travel and labor costs covered.
What is the average delivery lead time?
For equipment currently in stock, shipment takes 5-10 days. If out of stock, it takes 15-20 days for small format machines, 30 days for large format machines, and 7 days for personal care products.
Do you offer product samples?
Yes, we can provide samples for certain standard items free of charge, provided the customer covers the freight and transport costs.
What are the standard payment terms?
For orders below 5000 USD, 100% advance payment is required. For orders of 5000 USD and above, we require a 50% T/T deposit in advance, with the remaining balance cleared prior to shipment.
