| Parameter Item | Specification Detail | ||
|---|---|---|---|
| SLITTING LAYER | SINGLE LAYER | ||
| SLITTING WIDTH | 650 MM | ||
| SLITTING THICKNESS | 40–120 GR/M² | ||
| UNWINDING DIAMETER | 1200 MM | ||
| UNWINDING TYPE | AIR SHAFT | ||
| UNWINDING CORE SIZE | 3 INCH | ||
| UNWINDING BRAKE TYPE | MAGNETIC POWDER BRAKE | ||
| REWINDING WIDTH | 20 MM (MIN.) | ||
| REWINDING DIAMETER | 250 MM (MAX.) | ||
| REWINDING SHAFT | 8–50 MM | ||
| SLITTING UNIT | 10 PCS CIRCLE BLADES | ||
| WALL THICKNESS | 30 MM | ||
| MECHANICAL SPEED | 200 M/MIN (MAX.) | ||
| WORKING SPEED | 180 M/MIN (MAX.) | ||
| POWER SUPPLY | 380 V, 3 PHASES, 50 HZ, 2.2 KW | ||
| AIR POWER SUPPLY | 0.8 MPA (MIN.) | ||
| NET WEIGHT | 1500 KG | ||
| MACHINE SIZE | 1800 × 2000 × 1450 MM |
A. On-site Installation & Training: Technical support is available for factory machine installation and operator training. The customer is responsible for visa costs, round-trip airfare, accommodation, meals, and a daily service fee subsidy.
B. Training at Factory: Training options are also offered directly at the manufacturing facility. The customer is only required to cover accommodation expenses.
